Description
Ref.:	42431-26121
Name:	Brake Drum
Unit:	PCS
Price:
Rear Axle Height : 80.5 mm Inner Brake Drum Height : 66.5 mm Diameter : 330 mm Drum Diameter : 270 mm Center Diameter : 108 mm Pitch Circle Diameter : 139.7 mm Number Of Holes : 6

Model	Engine			Type	CYL	year
TOYOTA HIACE IV Box					9/95 - 8/01
HIACE IV Box 2.4 4WD (RCH18_, RCH28_)	2RZ-E	2438	116	Box	4	8/95 - 4/98
HIACE IV Box 2.4 TD 4WD (LXH18_, LXH28_)	2L-T	2446	90	Box	4	8/95 - /
HIACE IV Box 2.5 D-4D	2KD-FTV	2494	102	Box	4	1/01 - /
HIACE IV Box (LXH1_, LH1_, RZH1_) 2.4 D	2L	2446	75	Box	4	9/95 - 8/01
TOYOTA HIACE IV Wagon (H100)					8/01 - 8/06
HIACE IV Wagon (H100) 2.5 D-4D 4x4	2KD-FTV	2494	102	Bus	4	8/01 - 8/06
TOYOTA HIACE IV Wagon					1/01 - /
HIACE IV Wagon 2.4 4WD (RCH18_)	2RZ-E	2438	116	Bus	4	8/95 - 4/98
HIACE IV Wagon 2.7 (RCH13_, RCH23_)	3RZ-FE	2694	143	Bus	4	4/98 - 1/01
HIACE IV Bus (LH1_) 2.5 D-4D 4WD	2KD-FTV	2494	102	Bus	4	1/01 - 8/06
HIACE IV Wagon 2.4 TD 4WD (H18/28)	2L-T	2446	90	Bus	4	8/95 - /
HIACE IV Wagon 2.5 D-4D	2KD-FTV	2494	102	Bus	4	1/01 - /
TOYOTA HIACE V Box					9/06 - /
HIACE V Box 2.5 D-4D 4x4	2KD-FTV	2494	117	Box	4	9/06 - /
